High-speed 2D/3D Resistivity/IP/SP Imaging System Package - 28 Electrodes

This system package includes:

• SuperSting™ R8 Wi-Fi with Tablet Controller - Qty 1

• Cable of 14 electrodes (6.25m electrode spacing) - Qty 2 (making a total of 28 electrodes)

• SwitchBox Grid - Qty 1

• Key to use EarthImager™ Software (Your choice of 2D or 3D) - Qty 1

• Free admission for one person: 3-day training seminar (airfare & lodging not included) - Qty 1

Use Cases:

We’ve designed this 28-electrode system package to handle various jobs. Below are just a few use cases that this package would be ideal for:

• Mineral Exploration

  • Metallic mineral investigations

  • Non-Metallic mineral and aggregate mining investigations

• Geotechnical and Civil Engineering Investigations

  • Locating tunnels, caves, sinkholes, and fault- fractures

  • Dam and levee investigations

• Groundwater Exploration

  • Irrigation

  • Drinking water

  • Saline/freshwater interface mapping along coastlines and petroleum drilled areas

• Environmental and Monitoring Investigations

  • NAPL (DNAPL and LNAPL) pollution research for remediation of hydrocarbons

  • CO2 Sequestration Time-Lapse Monitoring

  • ASTM D7007: Geomembrane Leak Detection

• Bedrock and Landfill Mapping

• Grounding Surveys for Power Plants and Cell Phone Towers

• Archeological Investigation

• Borehole Logging

  • Short-Long-Leterolog-SP

  • Cross-borehole tomography

• IEEE Standard 81: Fall of Potential (FOP) Method

• ASTM G57: Wenner Soil Resistivity Test

• Underwater and Marine Studies

  • Determining sub-bottom geology for dredging purposes

  • Monitoring leakage in a dam

  • Mapping fresh and saltwater interfaces near shorelines or offshore

  • Characterizing the sub-bottom of estuaries

  • Measuring water column salinity variations

  • Mineral exploration (usually placer deposits)

  • Locating freshwater springs at sea (submarine groundwater discharge)

  • Distinguishing between hard rock, sand, gravel, silt, and clay

  • Gas Hydrate Exploration

  • Subsurface geotechnical site investigation for oil platforms

  • Sediment research

  • Fracture Imaging

  • Resistivity and IP studies for deep mining, oil/gas investigations

This system is qualified for 100% financing. Learn more.
